Architecture

System topology

TruConnect reaches the backend two ways, depending on the deployment shape:

  • Browser-mediated (connected site, has a frontend) — TruConnect streams live weight to the operator's browser over a local WebSocket; the browser is the one that calls the backend.
  • Direct-to-backend (frontend-less site) — TruConnect posts autoweigh/complete straight to truload-backend's API itself, and pulls Stations/AxleConfiguration reference data down from it (ConfigSyncService.js), with no browser in the loop at all. This is what a remote, low-connectivity site with no local frontend install runs, backed by TruConnect's own durable SQLite offline queue (SyncQueue.js) so captures survive an extended outage and sync exactly once on reconnect.
flowchart TD
  subgraph Station
    scale[Weighbridge scale]
    tc[TruConnect<br/>Windows bridge]
    browser[Operator browser]
    scale -->|serial/TCP/UDP/HTTP| tc
    tc -->|local WebSocket<br/>connected site| browser
  end

  subgraph Cluster["Kubernetes (Contabo, EU-Nuremberg)"]
    fe[truload-frontend]
    be[truload-backend]
    pg[(PostgreSQL)]
    rd[(Redis)]
    mq[(RabbitMQ)]
  end

  browser -->|HTTPS| fe
  fe -->|HTTPS| be
  tc -->|HTTPS direct<br/>frontend-less site<br/>autoweigh/complete + Stations/AxleConfig pull| be
  be --> pg
  be --> rd
  be --> mq

  be -->|invoice push / status| pf[Pesaflow / eCitizen]
  be -->|vehicle / driver lookups| ntsa[NTSA, KeNHA]

Components

truload-backend (.NET 10)

Controllers and services in Controllers/ and Services/Implementations/. Major modules:

  • Weighing — WeighingController, AxleConfigurationController, VehicleController, DriverController. Autoweigh endpoint, capture-weights update, compliance decision.
  • Case / yard / prosecution — CaseRegisterController, CourtHearingController, ComplianceCertificateController, YardController, VehicleTagController.
  • Financial — PaymentController, InvoiceController, ReceiptController, PaymentCallbackController.
  • Identity / RBAC — RolesController, PermissionsController, UsersController; ApplicationRole, Permission, RolePermission.
  • Reporting — ReportController, SupersetController.
  • Configuration — SettingsController, IntegrationConfigController, AuditLogController.

Background jobs run on Hangfire: reconciliation, document generation, scheduled backups.

truload-frontend (Next.js 15, React 19, TypeScript)

Module layout in src/app/[orgSlug]/:

  • weighing/ — capture, tickets, tags, yard
  • cases/ — register, court hearings, charges
  • users/modules/ — user, role, station, department admin
  • setup/ — initial setup wizard

Cross-cutting concerns:

  • src/lib/offline/ — IndexedDB via Dexie + background sync (service worker) for intermittent networks
  • src/lib/api/ — typed API client
  • src/hooks/queries/ — React Query per domain
  • src/components/integrations/, src/components/payments/ — Pesaflow checkout dialog, reconciliation panel

TruConnect (Electron + Node)

Pluggable adapter model:

  • src/parsers/ — ZmParser, CardinalParser, I1310Parser, MobileScaleParser, CustomParser
  • src/input/ — SerialInput, TcpInput, UdpInput, ApiInput
  • src/output/ — WebSocketOutput, ApiOutput, SerialRduOutput, NetworkRduOutput
  • src/core/ — EventBus, StateManager, ConnectionPool
  • src/database/ — better-sqlite3 with migrations
  • src/cloud/ — two-way sync with the backend
  • src/backend/ — direct backend integration for frontend-less deployments: BackendClient.js (auth + autoweigh/complete submission), SyncQueue.js (durable weighing_queue SQLite table, dependency-chained sends, per-call idempotency key, backoff, dead-letter), ConfigSyncService.js (Stations/AxleConfiguration/AxleWeightReference/ ToleranceSetting mirror + drift detection), ComplianceEngine.js (local provisional compliance decision for enforcement — a hand-port of truload-frontend's own offline engine — plus a lightweight commercial tare/gross/net resolver), LocalWeighingStore.js (local_weighings table, one row per physical weighing, so a capture can never be silently lost and the capture UI can show pending-sync state)
  • src/simulation/ — scripted feeds for regression runs

Data stores

  • PostgreSQL 17 with pgvector — transactional data and semantic search on prior violations.
  • Redis — session cache, permission cache, background-job progress.
  • RabbitMQ (2 nodes) — async jobs, document generation, notifications.

Transaction path

  1. Operator authenticates; backend issues JWT with role + permission claims.
  2. Frontend calls the relevant module endpoints.
  3. TruConnect streams live weight to the browser, which posts the capture to the backend (connected site) — or, at a frontend-less site, TruConnect posts autoweigh/complete straight to the backend itself, queuing locally first so a capture survives an outage.
  4. Compliance engine computes axle-group aggregation, tolerance, and the overload decision.
  5. Case register, yard entry, and prosecution records auto-create where applicable.
  6. Prosecution generates an invoice; payment is settled via Pesaflow; a receipt is generated on callback.
  7. Compliant reweigh triggers the auto-close cascade back to the case and yard entry.
